Electrical performance parameters (STC* ):
|
Module Type |
SF3-510 |
SF3-515 |
SF3-520 |
||
|
Max- Power |
PMPP |
[W] |
510 |
515 |
520 |
|
Power Tolerance |
[W] |
0~5W |
0~5W |
0~5W |
|
|
Max-Power Voltage |
VMPP |
[V] |
42.29 |
42.35 |
42.41 |
|
Max-Power Current |
IMPP |
[A] |
12.31 |
12.34 |
12.37 |
|
Open-Circuit Voltage |
Voc |
[V] |
49.76 |
49.83 |
49.9 |
|
Short-Circuit Current |
lsc |
[A] |
12.74 |
12.78 |
12.86 |
|
Max. series fuse rating |
[A] |
25 |
|||
|
Max. system voltage |
IEC/UL |
[V] |
1500V DC(IEC) |
STC*: Irradiance=1000 W/m², Module temperature=25℃, AM=1.5
Mechanicalparameters:
|
Cell Type |
Mono PERC 182mm*182mm |
|
Size |
2250*1200*1.8mm |
|
Thickness |
1.8mm (junction box not included) |
|
Weight! |
2.9 kg/m² |
|
Connector |
MC4 Compatible |
|
Junction-box |
Triad Junction box IP68 |
|
Backboard color |
Black/White |
Electrical performance parameters (NMOT * ):
|
Module Type |
|||||
|
Max- Power |
PMPP |
[W] |
395 |
399 |
403 |
|
Max-Power Voltage |
VMPP |
[V] |
39.37 |
39.43 |
39.49 |
|
Max-Power Current |
IMPP |
[A] |
10.37 |
10.4 |
10.43 |
|
Open-Circuit Voltage |
Voc |
[V] |
46.1 |
46.17 |
46.24 |
|
Short-Circuit Current |
Isc |
[A] |
10.72 |
10.76 |
10.84 |
NMOT*: Irradiance=800 W/m², Ambient temperature=20℃, Wind speed=1 m/s
Application parameters:
|
Max. system voltage |
DC 1500V |
|
Power Tolerance |
0~+5W |
|
Operating temperature range |
-40℃~+85℃ |
|
Max. series fuse rating |
25 A |
|
Mechanical Load |
2400Pa (Snow & Wind Load) |
Temperature coefficien:
|
Temperature-coefflcient of PMPP |
[%/℃] |
-0.37 |
|
Temperature-coefflcient of Voc |
[%/℃] |
-0.28 |
|
Temperature-coefflcient of lsc |
[%/℃] |
0.05 |
|
NOCT |
℃ |
45±2C |
Package:
|
Transportation |
Container size |
Quantity (pcs) |
Quantity (per pallet) |
|
Container |
40' HQ |
1260 |
70 |
|
Platform Trailer |
13m |
1400 |
70 |
|
Platform Trailer |
17.5m |
1960 |
70 |
